Measure Conductivity, Temperature, and Depth.
Continuously monitor groundwater and surface water level changes
along with electrical conductivity and temperature.
Decagon's CTD sensor puts much of the complex circuitry in an
above-water data logger. This lowers the per-sensor cost without
impacting accuracy and resolution. So instead of relying on a
single measurement, you can measure in several different
locations without exceeding your budget.
FEATURES
- Robust marine-grade epoxy overmold to resist corrosion in tough
environments.
- Compact 3.4 cm diameter sensorbody to fit into tight
spaces.
- External logger with remote transmission option to deliver the
mdata to your desktop.
- Permanent connection to collect data continuously without
pulling up the sensor.
| Specifications |
| Water Depth Range: |
0 to3.5m |
| Water Depth Accuracy: |
+/- 0.2% of span |
Water Depth Resolution:
|
1 mm |
Electrical Conductivity Range:
|
0 to 120 dS/m (mS/ cm)
|
Electrical Conductivity Accuracy:
|
+/- 5% of reading |
Electrical Conductivity Resolution:
|
1.2% of reading
|
| Temperature Range: |
-40 to +50ºC |
| Temperature Accuracy: |
+/- 1ºC |
Temperature Resolution:
|
0.1ºC |
| Data Logger Compatibility (not exclusive) |
Decagon: Em50, Em50R, Em50G and ProCheck
|
| Warranty |
One year, parts and labour |
